• Connection of a SpeakerCraft MZC-66 System. MZC-66 Quick Start focuses on a MZC-66 ‘default’ system, that is, a basic six zone system that includes up to six audio/video sources, that matches the MZC-66 default project included in the EZ-Tools download. This Quick Start Guide can also be used for getting more sophisti. • MASTER POWER Switch – When pressed to the in position, the MZC-66 is placed in the power ON standby condition, permitting individual zones to be turned ON and OFF by keypad or touch panel commands. In the OFF (out) position, power from the AC mains is completely turned off. • Source Audio signals to additional zone inputs on Slave MZC-66’s in expanded systems. The L, R, V LOOP on the MZC Master would connect to the appropriate L, R, V INPUT on MZC Slave 1.
Speakercraft EZ Tools Software. Anyone know where I can get a copy of this? The website/support requires a dealer login. Fl studio producer edition crack. Thanks ratt2581 is offline Quote.
• Function Buttons – These lower 4 buttons (5 buttons in the case of the MKP-1.0) can be programmed for any function except source select. IR Receiver Lens – EZ-Pad version MKP-1.1 includes SpeakerCraft’s exclusive ANS IR Receiver, built-in. The IR Receiver allows use of a handheld remote for control of system components. • 485A & 485B CAT-5 WITHOUT RJ45 CONNECTORS – Connect EZ-Pads to MZC-66 as shown above. Be sure to maintain consistent color code when making connections. For IMKP, use same pin-out. See MODE 3.1 Installation Instructions for plug-in connector and RJ45 pin-outs.
• “sub-zones” to a default system. Additionally, the MZC-66 has a programmable contact closure for control of lifts, screens, drapes etc.The MZC-66 also features two Doorbell/Status inputs that can be used for common source power management or tiggering a system ‘event’ from a doorbell module. For additional information on connec- tion, configuration and programming of these optional features see: MZC-66 Hardware Installation Instructions and EZ Tools MZC Programming Instructions. • Carefully attach a SpeakerCraft IR Emitter (Models: 1.0, 2.0, 3.0, 4.0) over the IR eye on the front panel of each external source component to be controlled via infrared. Carefully pull the emitter wire to the rear panel of the MZC-66.
Do not block accesses for discs and tapes. Do not pinch emitter wires between components. • *5-3⁄4” (146mm) H, includ-ing feet Input/Output Levels 1.0V p-p +/- 5% (Outputs 75 Ohms Terminated) Weight 23 lbs (10.5 kg) 940 Columbia Ave., Riverside CA 92507 USA (800) 448 0976 Fax (951) 787 8747 International +1 951 787 0543 www.speakercraft.com LIT13166.
Speakercraft is a manufacturer of home theatre, audio and video equipment. Speakercraft products can only be custom-installed by authorised dealers. Speakercraft makes various tools and software, including EZ Tools, available for download on its website. The EZ Tools software allows dealers to program Speakercraft equipment in order to make adjustments. These downloads are available only to custom installers, not to the public.
Custom installers can register their company on the Speakercreaft website and create an account to access the feature. Navigate to Speakercraft's website. Click the 'Resources' tab on the navigation bar, then click 'For Custom installers' in the drop-down menu. Click the 'Dealer Resource Center' button. This is located next to the 'Speakercaft ideas' button at the bottom of the page.
A list of available resources will be displayed. Click the 'Software' button.
Enter a username and password into the required fields to access dealer-only software. The username is the one that was chosen when the company registered to become a Speakercreaft custom installer. The password will be the one sent to the email adress that was provided during the registration process. Click the 'Login' button to proceed to a list of available software. Click the 'EZ Tools' button, then click 'download.'
